Product Summary

The FS225R12KE3 is an IGBT module.

Parametrics

FS225R12KE3 absolute maximum ratings: (1)collector-emitter voltage: 1200V; (2)dc-collector current: 225A; (3)repetitive peak collector curren: 450A; (4)total power dissipation: 1150W; (5)gate-emitter peak voltage: ±20V.

Features

FS225R12KE3 features: (1)collector emitter saturation voltage: 200V; (2)gate threshold voltage: 65V; (3)gate charge: 210μC; (4)internal gate resistor: 33Ω; (5)reverse transfer capacitance: 0.75nF.

Diagrams

FS225R12KE3 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FS225R12KE3
FS225R12KE3

Infineon Technologies

IGBT Modules 1200V 225A 3-PHASE

Data Sheet

0-1: $305.81
1-10: $275.23
