Product Summary

The CM400YE2P-12F is an IGBT module. Its applications include three level inverter topologies, solar power inverters, high efficiency UPS, long motor lead applications.

Parametrics

CM400YE2P-12F absolute maximum ratings: (1)Junction temperature: -40 to 150℃; (2)storage temperature: -40 to 125℃; (3)isolation voltage: 2500Vrms; (4)collector-emitter volage: 600V; (5)gate-emitter voltage: ±20V; (6)collector current DC: 400A.

Features

CM400YE2P-12F features: (1)smaller output voltage steps reducing surge voltage; (2)low output ripple current; (3)lower modulation frequency with same quality output waveform.

Diagrams

CM400YE2P-12F diagram
